Nicotra Forward Curved Centrifugal Fan ADH 1250 X1 from D.P. Engineers, Delhi. Suitable for HVAC, AHU, ventilation and industrial air movement applications. Supplier & dealer across India.
The Nicotra Forward Curved Centrifugal Fan ADH 1250 X1 Is A Premium-Duty, Belt-Driven, Double Inlet Double Width (DWDI) Centrifugal Fan Engineered For High-Volume Air Movement In Commercial And Industrial HVAC Systems. Designed For Continuous Operation, It Delivers Reliable Airflow, Low Vibration, And Energy-Efficient Performance For Demanding Ventilation And Air-Handling Applications. The ADH Series Is AMCA-Certified For Air Performance And Is Widely Used In Large AHUs And Ventilation Systems.
Key Features – Nicotra
Heavy-Duty Forward Curved DWDI Iimpeller
- High Airflow With Stable Static Pressure Performance
- Low Noise And Low Vibration Operation
- Robust Steel Construction For Long Service Life
- Suitable For Belt-Driven Transmission Systems
- High Efficiency For Reduced Energy Consumption
- Precision Balanced Impeller For Smooth Running
- Easy Installation And Maintenance
- Reliable Continuous-Duty Industrial Performance
- Compatible With Large Air Handling Units (AHUs)
- Designed For Commercial And Industrial HVAC Applications
- AMCA-Certified Air Performance (ADH Series).
Applications – Nicotra
Air Handling Units (AHUs)
- HVAC Ventilation Systems
- Clean Rooms
- Pharmaceutical Manufacturing Plants
- Hospitals And Healthcare Facilities
- Commercial Buildings
- Shopping Malls
- Hotels
- Food Processing Industries
- Textile Industries
- Electronic Manufacturing Units
- Industrial Ventilation Systems
- Fresh Air Supply Systems
- Exhaust Air Systems
- OEM HVAC Equipment
Product Specifications – Nicotra
| Specification | Details |
|---|---|
| Product Name | Nicotra Forward Curved Centrifugal Fan |
| Model | ADH 1250 X1 |
| Fan Type | Forward Curved, Double Inlet Double Width (DWDI) |
| Drive Type | Belt Driven |
| Impeller Material | Heavy-Duty Steel |
| Housing Material | Steel |
| Voltage | 400 V AC (Typical) |
| Frequency | 50 Hz |
| Phase | Three Phase |
| Motor Power | 15 kW (Typical Configuration) |
| Rotation | Clockwise / Counter-Clockwise (As Required) |
| Mounting | Horizontal |
| Operating Duty | Continuous |
| Features | High Airflow, Low Noise, Energy Efficient, Durable Construction |
| Applications | HVAC, AHU, Industrial Ventilation, Clean Rooms, Pharmaceutical Plants |
Notes:
- Airflow: Up to 38,000 m³/h (≈22,400 CFM).
- Motor Power And RPM Vary According To The Required Airflow And Static Pressure.
- Static Pressure And Performance Should Be Selected From The Official Nicotra Performance Curves For The Required Duty Point.
